This unit machine is special design for packaging various vegetable like White radish, cucumber, lettuce, cabbage in to plastic bag .The whole machine have the function of automatic product feeding ,weighing ,film bag forming ,bag sealing ,Including date coding ,bag counting .The finished bag is output from conveyor machine which no need manual collect the bag and avoid the bag polluting .
Приложение:
It is suitable for quantitative weighing of large target weight or large volume materials such as vegetable salad, fruit salad, potatoes, onions, tomatoes, cherry tomatoes and other vegetables and fruits.
Характеристика:
- Special load cell with high precision and high standard.
- Program recovery function can reduce operation failures, support multi-segment weight calibration.
- No products auto pause function can improve weighing stability and accuracy.
- Linear amplitude can be adjusted independently, can make the feeding more uniform.
- 15 languages available for global markets.
- 100 programs capacity can meet various weighing requirement, user-friendly help menu in touch screen contributes to easy operation.
Въведение :
Тази машина може автоматично да реализира функции за производство на торби, пълнене, запечатване, печат, рязане и т.н. Тази машина може автоматично да достигне до формирането на торби, пълнене и запечатване.
Тази опаковъчна машина използва импортиран серво мотор за подаване на филми, а интерфейсът човек-машина използва усъвършенстван сензорен екран. Работата е по-проста и удобна. Всички компоненти приемат международно известна марка, PLC е SIEMENS, серво моторът е PANASONIC, сензорният екран е SIEMENS, цилиндърът и въздушният клапан са SMC. части, които са в контакт с материала 、 контролен шкаф 、 основна рамка са изработени от неръждаема стомана304
Технически параметри:
| Модел | ZL780 |
| Forming bag type | Pillow bag/gusseted bag |
| Дължина на чанта | 150-480mm by secondary film pulling the bag length can be longer |
| Ширина на чанта | 120-375mm(Side width +front width ) |
| Широчина на филма | ≤780mm |
| Bag forming speed | 5-15bag/min |
| Air source consumption | 0.8MPa 0.45m3/min |
| Max outer diameter of reel | ¢400mm |
| Core inner dia | ¢75mm |
| мощност | 6KW 380V±10% 50Hz |
| Размер на машината | 1650*1500*1750mm |
| Тегло на машината | 650 кг |
